Wacker Neuson
ModelGasoline Cut-off Saw BTS635s
Demolition
The high-quality components make the BTS635s gasoline cut-off saw an ideal tool for the construction site. You too can benefit!
Model / part number: BTS635S
Technical data covers 1 configurations or components. Compare the specific options below.
Technical specifications
16 specifications · 1 configurations or components
Technical Data16 details
BTS635s16 specifications
- Cutting depth max.
- 12.8 cm
- Length
- 825 mm
- External diameter of pressure disk min.
- 90 mm
- Spindle diameter
- 25.4 mm
- Width
- 315 mm
- Height
- 420 mm
- Weight
- 11.6 kg
- Cutting wheel diameter min.
- 300 mm
- Cutting wheel diameter max.
- 350 mm
- Mounting hole of wheel
- 25.4 mm
- Cylinder capacity
- 86 cm³
- Fuel consumption
- 2.3 l/h
- Tank capacity
- 1.1 l
- Effective power
- 3.7 kW
- Nominal Engine speed
- 9,300 1/min
- CO2 (NRSC)
- 840 g/KWh
