Wacker Neuson
ModelHigh-frequency internal vibrators IRFU
Concrete Technology
Easily connects to the single-phase power supply and is ready for operation. The IRFU high-frequency internal vibrator series: benefit now from the advantages!
Technical data covers 5 configurations or components. Compare the specific options below.
Technical specifications
55 specifications · 5 configurations or components
Technical Data55 details
IRFU30/230/511 specifications
- Nominal current
- 2.2 A
- Nominal voltage
- 220–240 V
- Nominal frequency
- 50–60 Hz
- Nominal power
- 0.40 kW
- Phase
- 1 ~
- Vibrations
- 12,000 1/min
- Head diameter
- 30 mm
- Hose length
- 5 m
- Weight
- 12.5 kg
- Cable length
- 15 m
- Degree of protection
- IP67
IRFU38/230/511 specifications
- Nominal current
- 3.5 A
- Nominal voltage
- 220–240 V
- Nominal frequency
- 50–60 Hz
- Nominal power
- 0.65 kW
- Phase
- 1 ~
- Vibrations
- 12,000 1/min
- Head diameter
- 38 mm
- Hose length
- 5 m
- Weight
- 14.6 kg
- Cable length
- 15 m
- Degree of protection
- IP67
IRFU45/230/511 specifications
- Nominal current
- 4.8 A
- Nominal voltage
- 220–240 V
- Nominal frequency
- 50–60 Hz
- Nominal power
- 0.88 kW
- Phase
- 1 ~
- Vibrations
- 12,000 1/min
- Head diameter
- 45 mm
- Hose length
- 5 m
- Weight
- 17 kg
- Cable length
- 15 m
- Degree of protection
- IP67
IRFU58/230/511 specifications
- Nominal current
- 6 A
- Nominal voltage
- 220–240 V
- Nominal frequency
- 50–60 Hz
- Nominal power
- 1.10 kW
- Phase
- 1 ~
- Vibrations
- 12,000 1/min
- Head diameter
- 58 mm
- Hose length
- 5 m
- Weight
- 20.8 kg
- Cable length
- 15 m
- Degree of protection
- IP67
IRFU65/230/511 specifications
- Nominal current
- 10 A
- Nominal voltage
- 220–240 V
- Nominal frequency
- 50–60 Hz
- Nominal power
- 1.84 kW
- Phase
- 1 ~
- Vibrations
- 12,000 1/min
- Head diameter
- 65 mm
- Hose length
- 5 m
- Weight
- 25.2 kg
- Cable length
- 15 m
- Degree of protection
- IP67
