Wacker Neuson
ModelPortable frequency converters FUE
Concrete Technology
Light and compact design: the frequency converters of the FUE series. Find more information on the official Wacker Neuson website!
Technical data covers 2 configurations or components. Compare the specific options below.
Technical specifications
43 specifications · 2 configurations or components
Technical Data43 details
FUE M/S 75A 6CEE-32A22 specifications
- Nominal current
- 13 A
- Nominal voltage
- 400–415 V
- Nominal frequency
- 50–60 Hz
- Output current
- 75 A
- Output voltage
- 42 V
- Output frequency
- 0–200 Hz
- Phase
- 3 ~
- Dimensions (L × W × H)
- 520 × 310 × 494 mm
- Weight
- 29.5 kg
- Sockets
- 6
- Protection class
- I / Protective earthing
- Item number
- 5000610194
- Output phase
- 3 ~
- Length
- 520 mm
- Width
- 310 mm
- Height
- 494 mm
- Operating indicator
- Yes
- Frequency adjustment
- Yes
- Cable length
- 2.5 m
- Input plug
- CEE plug, 5-pole, 16 A, 400 V, 6 h
- Receptacle type
- CEE, 3-pole, 32 A, 50 V, 100–200 Hz
- Degree of protection
- IP44
FUE-M/S 85A 4CEE-32A21 specifications
- Nominal current
- 13.7 A
- Nominal voltage
- 400–415 V
- Nominal frequency
- 50–60 Hz
- Output current
- 85 A
- Output voltage
- 42 V
- Phase
- 3 ~
- Dimensions (L × W × H)
- 500 × 500 × 550 mm
- Weight
- 42 kg
- Sockets
- 4
- Protection class
- I / Protective earthing
- Item number
- 5000108479
- Output phase
- 3 ~
- Length
- 500 mm
- Width
- 500 mm
- Height
- 550 mm
- Operating indicator
- Yes
- Frequency adjustment
- Yes
- Cable length
- 2.5 m
- Input plug
- CEE plug, 5-pole, 16 A, 400 V, 6 h
- Receptacle type
- CEE, 3-pole, 32 A, 50 V, 100–200 Hz
- Degree of protection
- IP44
