John Deere
Model8RT 410 Tractor
Row Crop 4WD Tractors
Discover the John Deere 8RT 410 tractor with 410 hp, integrated precision ag technology, advanced suspension, and tracked performance.
Model / part number: 8230RW
Key specifications
- Engine Make
- John Deere PowerTech 9.0 L (B20 diesel compatible)
- Engine Model
- PowerTech™ 9.0 L
- Engine Family
- MJDXL09.0333
- Displacement (Imperial)
- 549 cu in.
Technical specifications
97 specifications
Key Specs12 details
- Engine Make
- John Deere PowerTech 9.0 L (B20 diesel compatible)
- Engine Model
- PowerTech™ 9.0 L
- Engine Family
- MJDXL09.0333
- Displacement (Imperial)
- 549 cu in.
- Displacement (Other)
- 9.0 L
- Rated Engine Power
- 302 kW
- Maximum Engine Power
- 326 kW
- Transmission Type
- Standard: e23™ PowerShift™ with Efficiency Manager 40K, 40 km/h (25 mph); Optional: John Deere eAutoPowr EVT 40K, 0.05-42 km/h (0.03-26 mph)
- Rear Hitch Category (SAE Designation)
- Category 4N/3 at 610 mm (24 in.) behind hitch point: 9072 kg / 20,000 lb; Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg / 15,000 lb
- Pump Rated Output
- 85-cc pump: 227.1 L/min (60 gpm)
- Base Machine Weight (Imperial)
- 34400 lb.
- Base Machine Weight (Metric)
- 15600 kg
Machine Configuration2 details
- Wheel or Track Configuration
- 2-Track
- Drive Type
- 4WD
Engine20 details
- Engine Make
- John Deere PowerTech 9.0 L (B20 diesel compatible)
- Engine Model
- PowerTech™ 9.0 L
- Engine Family
- MJDXL09.0333
- Emissions Certifications
- Final Tier 4
- Displacement (Imperial)
- 549 cu in.
- Displacement (Other)
- 9.0 L
- Aspiration
- Dual turbochargers, variable geometry turbo with fixed geometry turbo in series; air-to-air aftercooling and cooled exhaust gas recirculation
- Number of Cylinders
- 6
- Cylinder Liners
- Wet-sleeve
- Aftertreatment Type
- Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR)
- Rated Engine Speed
- 2100 rpm
- Rated Engine Power
- 302 kW
- Engine Torque at Rated Speed (Imperial)
- 1365.0 lb-ft
- Engine Torque at Rated Speed (Metric)
- 1851 Nm
- Maximum Engine Power
- 326 kW
- Maximum Engine Torque
- At 1600 rpm: 1851 Nm / 1365 lb-ft
- Power Bulge
- 8 %
- Fuel Type
- Diesel
- Alternative Fuel Type
- B20 diesel compatible
- Torque Rise
- 40 %
Transmission3 details
- Transmission Type
- Standard: e23™ PowerShift™ with Efficiency Manager 40K, 40 km/h (25 mph); Optional: John Deere eAutoPowr EVT 40K, 0.05-42 km/h (0.03-26 mph)
- Maximum Speed Forward
- Standard: 40 km/h (25 mph); Optional: 42 km/h (26 mph)
- Minimum Speed Forward
- 0.05 km/h (0.03 mph)
Rear Power Take-Off (PTO)7 details
- PTO Category
- 45 mm (1.75 in.) 20-spline, 1000 rpm
- Rated PTO Power (Imperial)
- 310 hp
- Rated PTO Power (Metric)
- 231 kW
- Rated PTO Power (Other)
- 315 PS
- Engine rpm at Rated PTO Speeds (540/1.000)
- 1,000 PTO rpm: 2,000 rpm
- Engagement Method
- Electrohydraulic with adjustable modulation
- Number of Splines
- 20
Rear Hitch4 details
- Rear Hitch Category (SAE Designation)
- Category 4N/3 at 610 mm (24 in.) behind hitch point: 9072 kg / 20,000 lb; Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg / 15,000 lb
- Maximum Lift Capacity at 610 mm Behind Hitch Point
- Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg 26,729 lb
- Lift Capacity Through Full Lift Range at 610 mm Behind Hitch Point
- Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg 26,729 lb
- Sensing Type
- Electrohydraulic
Drawbar2 details
- Drawbar Category
- Category 4 with heavy-duty support; Optional: Category 4
- Maximum Vertical Load
- 4990 lb / 11,000 lb; Optional: 2245 kg / 4950 lb
Hydraulics5 details
- Hydraulic System Type
- Closed-center, pressure/flow compensated system with load sensing
- Pump Rated Output
- 85-cc pump: 227.1 L/min (60 gpm)
- Number of Rear Selective Control Valves (SCVs)
- Standard: 1.3-cm (1/2-in.) ISO couplers: 4; Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available
- Available Flow at a Single Rear SCV
- 1.3-cm (1/2-in.) couplers: 132 L/min (35 gpm)
- SCV Control
- Electronic
Rear Axle1 detail
- Final Drive
- Inboard planetary three pinion
Steering & Brakes1 detail
- Steering Type
- Electric command steering with electric pump backup
Tracks4 details
- Track Drive Type
- Camso® 4500 General Ag Series - friction drive track belts
- Track Tread Spacing
- 1828.8 to 3048 mm / 72 to 120 in.
- Track Width
- Standard: 635 mm / 25 in.; Available: 419 mm / 16.5 in.; 457 mm / 18 in.; 609 mm / 24 in.; 762 mm / 30 in.
- Number Of Mid Rollers
- Three
Electrical System5 details
- Battery Voltage
- 12 V
- Battery Cold Cranking Amps
- 1900 CCA
- Alternator Capacity
- 200 amp; 330 amp optional
- Working Lights
- 18 halogen; Available: 20 light-emitting diode (LED) or 24 LED
- Driving Lights
- Halogen, 65 W; Available: LED
Operator Station11 details
- Seat Suspension
- Air suspension
- Degree of Seat Swivel, Left Hand
- 25 degree (angle)
- Degree of Seat Swivel, Right Hand
- 40 degree (angle)
- Cab Suspension
- Four-post cab suspension
- Instructional Seat
- Standard
- Primary Display
- G5ᴾˡᵘˢ 12.8 in. (325 mm)
- Radio
- AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna
- Inner Cab Volume (Imperial)
- 114.0 cu ft
- Inner Cab Volume (Metric)
- 3.24 m³
- Cab Glass Area (Imperial)
- 70.18 sq ft
- Cab Glass Area (Metric)
- 6.52 m²
Technology Integration3 details
- Guidance
- Integrated AutoTrac™
- Connectivity
- JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination)
- Remote Diagnostics
- JDLink hardware standard
Capacities10 details
- Fuel Tank Capacity (Imperial)
- 202 gal.
- Fuel Tank Capacity (Metric)
- 764 L
- Diesel Exhaust Fluid (DEF) Tank Capacity (Imperial)
- 8.3 gal.
- Diesel Exhaust Fluid (DEF) Tank Capacity (Metric)
- 31.3 L
- Cooling System Capacity (Imperial)
- 11.2 / 12.4 gal.
- Cooling System Capacity (Metric)
- 42.3 / 46.9 L
- Transmission Hydraulic System (Imperial)
- 52 gal.
- Transmission Hydraulic System (Metric)
- 197 L
- Crankcase Oil Volume (Imperial)
- 6.8 gal.
- Crankcase Oil Volume (Metric)
- 25.7 L
Dimensions & Weights6 details
- Base Machine Weight (Imperial)
- 34400 lb.
- Base Machine Weight (Metric)
- 15600 kg
- Maximum Ballast Level (Imperial)
- 39000 lb.
- Maximum Ballast Level (Metric)
- 17700 kg
- Maximum Permissible Weight (Imperial)
- 40100 lb.
- Maximum Permissible Weight (Metric)
- 18200 kg
Additional Information1 detail
- Country of Manufacture
- USA
