John Deere
Model8R 250 Tractor
Row Crop 4WD Tractors
The John Deere 8250R delivers powerful performance, integrated precision agriculture, and advanced operator comfort to help farmers boost productivity, accuracy, and efficiency in every field operation.
Model / part number: 8110RW
Key specifications
- Engine Model
- PowerTech 9.0 L
- Engine Family
- MJDXL09.0333
- Displacement
- 549 cu in.
Technical specifications
37 specifications
Key Specs3 details
- Engine Model
- PowerTech 9.0 L
- Engine Family
- MJDXL09.0333
- Displacement
- 549 cu in.
Machine Configuration2 details
- Wheel or Track Configuration
- Wheel
- Drive Type
- 4WD
Engine10 details
- Engine Model
- PowerTech 9.0 L
- Engine Family
- MJDXL09.0333
- Emissions Certifications
- Final Tier 4
- Displacement
- 549 cu in.
- Aspiration
- Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation
- Cylinder Liners
- Wet-sleeve
- Aftertreatment Type
- Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR)
- Fuel Type
- Diesel
- Alternative Fuel Type
- B20 Diesel Compatible
- Torque Rise
- 40 %
Rear Power Take-Off (PTO)6 details
- PTO Category
- Standard: 45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 45 mm (1.75 in.), 20-spline, 1000/1000E rpm
- Economy PTO Speeds
- 1000E rpm
- Engine rpm at Rated PTO Speeds (540/1.000)
- 1810 / 1995
- Engine rpm at Rated PTO Speeds (540 E/1000/1.000 E)
- -- / 1995 / 1590
- Engagement Method
- Electrohydraulic with adjustable modulation
- Number of Splines
- 20
Front PTO2 details
- PTO Speed
- 1000
- Front PTO Rotation
- 35 mm (1.375 in.) 21 spline, 1000 rpm; 45 mm (1.75 in.) 20 spline, 1000 rpm (available through parts only); 35 mm (1.375 in.) 6 spline, 1000 rpm (available dependent on location)
Front Hitch1 detail
- Front Hitch Category
- Category 3N
Drawbar1 detail
- Drawbar Category
- Standard: Category 3; Optional: Category 4 or Category 4 with heavy-duty support
Hydraulics2 details
- Hydraulic System Type
- Closed-center, pressure/flow compensated system with load sensing
- Available Flow at a Single Rear SCV
- 1.3-cm (1/2-in.) couplers: 132 L/min (35 gpm)
Front Axle2 details
- Front Axle Type
- 1300 Series MFWD; Optional: 1500 Series MFWD, ILS
- Front Axle Differential Lock
- 1300 Series MFWD: Limited Slip; ILS / 1500 Series MFWD: Full-locking electrohydraulic
Rear Axle1 detail
- Final Drive
- Inboard planetary three pinion
Tires1 detail
- Central Tire Inflation System (CTIS)
- Optional
Electrical System2 details
- Alternator Capacity
- 200 amp / 330 amp optional
- Driving Lights
- Halogen (65 W) / LED optional
Operator Station1 detail
- Cab Suspension
- Adjustable cab suspension
Technology Integration2 details
- Guidance
- Integrated AutoTrac™; Autonomy Ready (available in select regions)
- Connectivity
- JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination)
Additional Information1 detail
- Country of Manufacture
- USA
