John Deere
7M 215 Tractor
Row Crop 4WD Tractors
John Deere 7M 215 tractor with PowerTech™ engine, G5 Display, CommandQuad™ transmission, JDLink™ connectivity, and TLS™ suspension.
Current product detail page listed in the official John Deere AFME sitemap; this does not assert a 2026 model year or confirmed Eswatini stock.
The AFME sitemap includes model-year-specific and legacy listings. Confirm current model, configuration, and Eswatini availability with SwaziTrac before quoting.
Model / part number: 701MBM
Technical specification source: Official manufacturer technical data
Catalogue source: John Deere Africa & Middle East (AFME) · Checked 2026-10-04
Specifications
Key Specs12 specifications
- Engine Make
- John Deere
- Engine Family
- 6068HBM08
- Displacement
- 6.8 L
- Rated Engine Power (Imperial)
- 215 hp
- Rated Engine Power (Metric)
- 158 kW
- Maximum Engine Power (Imperial)
- 230 hp
- Maximum Engine Power (Metric)
- 169 kW
- Transmission Type
- John Deere AutoQuad™ 16F/16R - 30 km/h 18.6 mph John Deere CommandQuad™ 20F/20R with Efficiency Manager™ - 40 km/h 24.9 mph
- Rear Hitch Category (SAE Designation)
- 3-Point Hitch Cat. 3/3N - 4600 kgf at 610 mm - With Hook and Electronic Sensing Control 3-Point Hitch Cat. 3/3N - 6350 kgf at 610 mm - With Hook and Electronic Sensing Control
- Pump Rated Output
- 174 L/min; 46 gpm
- Base Machine Weight (Imperial)
- 22950 lb.
- Base Machine Weight (Metric)
- 10410 kg
Engine15 specifications
- Engine Make
- John Deere
- Engine Family
- 6068HBM08
- Emissions Certifications
- 14/10000 PROCONVE MAR-I
- Displacement
- 6.8 L
- Aspiration
- Single Wastegate Turbocharger with Air-to-Air Aftercooling and Cooled Exhaust Gas Recirculation (EGR)
- Number of Cylinders
- 6
- Cylinder Liners
- Wet Sleeve Cylinder Liners
- Rated Engine Speed
- 2100 rpm
- Rated Engine Power (Imperial)
- 215 hp
- Rated Engine Power (Metric)
- 158 kW
- Maximum Engine Power (Imperial)
- 230 hp
- Maximum Engine Power (Metric)
- 169 kW
- Maximum Engine Torque
- At 1550 r. p. m. : 904 Nm 667 lb-ft
- Power Bulge
- 7 %
- Fuel Type
- Diesel
Transmission1 specifications
- Transmission Type
- John Deere AutoQuad™ 16F/16R - 30 km/h 18.6 mph John Deere CommandQuad™ 20F/20R with Efficiency Manager™ - 40 km/h 24.9 mph
Rear Power Take-Off (PTO)5 specifications
- PTO Category
- PTO Cat. 2
- Rated PTO Power (Imperial)
- 184 hp
- Rated PTO Power (Metric)
- 135 kW
- Engagement Method
- Electrohydraulic
- Number of Splines
- 21
Rear Hitch3 specifications
- Rear Hitch Category (SAE Designation)
- 3-Point Hitch Cat. 3/3N - 4600 kgf at 610 mm - With Hook and Electronic Sensing Control 3-Point Hitch Cat. 3/3N - 6350 kgf at 610 mm - With Hook and Electronic Sensing Control
- Maximum Lift Capacity Directly at Coupling Points
- Category 3/3N: 6350 kg14 000 lb
- Sensing Type
- Electrohydraulic system with load control
Drawbar2 specifications
- Drawbar Category
- Category 3
- Maximum Vertical Load
- Base: Category 3 with heavy-duty drawbar support 4536 kg 10,000 lb
Hydraulics5 specifications
- Hydraulic System Type
- Closed center, with flow and pressure compensated
- Pump Rated Output
- 174 L/min; 46 gpm
- Number of Rear Selective Control Valves (SCVs)
- Standard: Four 1.3-cm (3-in.) couplers Optional: Four to six 1.3-cm (3-in.) couplers factory installed
- Available Flow at a Single Rear SCV
- 1.3-cm (3-in.) couplers: 132-L/min (44.5-gpm) 35 gpm
- SCV Control
- Standard: Mechanical Optional - Electronic
Front Axle2 specifications
- Front Axle Type
- Standard: 1150 Series Heavy Duty MFWD Front Axle Option: 1150 Series Front-Wheel Drive, Wide, Heavy-Duty Axle for 3-m (10.8-ft) tread setting Option: 1150 Series Triple Link Suspension (TLS) Axle
- Front Axle Differential Lock
- Electrohydraulic Full Lock System
Rear Axle3 specifications
- Rear Axle Type
- Rack & Pinion 100mm diameter long axle - 2808mm length
- Rear Differential Lock
- Electrohydraulic Full Lock System
- Final Drive
- Reduction by three planetary gears
Steering & Brakes1 specifications
- Steering Type
- Standard - Hydraulic power steering
Electrical System5 specifications
- Battery Voltage
- 12 V
- Battery Cold Cranking Amps
- 1850 CCA
- Alternator Capacity
- Standard: 200 amp
- Working Lights
- Standard: 10 light-emitting diodes (LED)
- Driving Lights
- Standard: LED
Operator Station8 specifications
- Seat Suspension
- Standard: Air suspension
- Degree of Seat Swivel, Left Hand
- 8 degree (angle)
- Degree of Seat Swivel, Right Hand
- 16 degree (angle)
- Cab Suspension
- No
- Instructional Seat
- Standard equipment
- Primary Display
- Standard: G5Plus Universal Display 32.5 cm (10 in.) 12.8 in. Optional: G5Plus CommandCenter™ 32.5 cm (10 in.) and Extended Monitor
- Radio
- Standard: AM/FM and Bluetooth® functions, USB port for charging smartphones, four speakers
- Inner Cab Volume
- 115.0 cu ft
Technology Integration2 specifications
- Guidance
- AutoTrac™ Integrated
- Remote Diagnostics
- Available with activated JDLink™ activations and hardware
Capacities8 specifications
- Fuel Tank Capacity (Imperial)
- 113.5 gal.
- Fuel Tank Capacity (Metric)
- 430 L
- Cooling System Capacity (Imperial)
- 7.66 gal.
- Cooling System Capacity (Metric)
- 29 L
- Transmission Hydraulic System (Imperial)
- 28.53 gal.
- Transmission Hydraulic System (Metric)
- 108 L
- Crankcase Oil Volume (Imperial)
- 6.86 gal.
- Crankcase Oil Volume (Metric)
- 26 L
Dimensions & Weights10 specifications
- Wheelbase (Imperial)
- 112.6 in.
- Wheelbase (Metric)
- 2860 mm
- Base Machine Weight (Imperial)
- 22950 lb.
- Base Machine Weight (Metric)
- 10410 kg
- Overall Length (Imperial)
- 229.3 in.
- Overall Length (Metric)
- 5824 mm
- Drawbar Ground Clearance (Imperial)
- 20.7 in.
- Drawbar Ground Clearance (Metric)
- 527 mm
- Maximum Ballast Level (Imperial)
- 26015 lb.
- Maximum Ballast Level (Metric)
- 11800 kg
Additional Information2 specifications
- Country of Manufacture
- Brazil
- Date Collected
- 18 October 2022
