John Deere
1795 Planter - Twenty-Four Row - 20 In. Planter
Drawn Planters
The 1795 is a drawn split-row planter that attaches to the drawbar or 2-point hitch of the tractor. This 30-ft model is available as a 12-row 30-in. planter that is a 23-row split row planter in the 15-in. row spacing configuration.
Current product detail page listed in the official John Deere AFME sitemap; this does not assert a 2026 model year or confirmed Eswatini stock.
The AFME sitemap includes model-year-specific and legacy listings. Confirm current model, configuration, and Eswatini availability with SwaziTrac before quoting.
Model / part number: 618WH
Technical specification source: Official manufacturer technical data
Catalogue source: John Deere Africa & Middle East (AFME) · Checked 2026-10-04
Specifications
Key Specs6 specifications
- Number Of Rows
- 24
- Frame Flexibility Up
- 15.0 degree (angle)
- Frame Flexibility Down
- 15.0 degree (angle)
- Seed Hopper Capacity (Imperial)
- 0.062 bu
- Seed Hopper Capacity (Metric)
- 2.2 L
- Base Seed Meter
- Vacuum
Rows and Row Spacing3 specifications
- Number Of Rows
- 24
- Row Spacing (Imperial)
- 20 in.
- Row Spacing (Metric)
- 51 cm
Frame2 specifications
- Frame Flexibility Up
- 15.0 degree (angle)
- Frame Flexibility Down
- 15.0 degree (angle)
Lift System1 specifications
- Type
- Wheel modules with rephasing hydraulic cylinders
Tires1 specifications
- Base
- Wing tires: 7.50-20 6PR implement tire; Center tires: VF295/75R22.5
Row Units4 specifications
- Type
- Standard: MaxEmerge™ 5 row units; Optional: ExactEmerge™ row units MaxEmerge 5e row-units
- Opener
- Tru-Vee™ double disk
- Seed Hopper Capacity (Imperial)
- 0.062 bu
- Seed Hopper Capacity (Metric)
- 2.2 L
Seed Meters5 specifications
- Base Seed Meter
- Vacuum
- CCS Seed Capacity Without Liquid Tank (Imperial)
- 130.0 bu
- CCS Seed Capacity Without Liquid Tank (Metric)
- 4581.0 L
- CCS Seed Capacity With Liquid Tank (Imperial)
- 100.0 bu
- CCS Seed Capacity With Liquid Tank (Metric)
- 3524.0 L
Drive System1 specifications
- Base
- Hydraulic variable rate drive
Markers1 specifications
- Type
- Automatic alternating or independent control
Seed Monitor System1 specifications
- Base
- SeedStar™ on GreenStar™ displays
Fertilizer3 specifications
- Tank Capacity (Imperial)
- 420.0 gal.
- Tank Capacity (Metric)
- 1590.0 L
- Exact Rate Fluid Transfer System
- Available
Dimensions10 specifications
- Transport Width (With Markers) (Imperial)
- 13.27 ft
- Transport Width (With Markers) (Metric)
- 4.043 m
- Transport Length (Imperial)
- 34.2 ft
- Transport Length (Metric)
- 10.425 m
- Transport Height (Imperial)
- 13.37 ft
- Transport Height (Metric)
- 4.075 m
- Field Operation Width (Imperial)
- 43.35 ft
- Field Operation Width (Metric)
- 13.212 m
- Field Operation Length (Imperial)
- 25.96 ft
- Field Operation Length (Metric)
- 7.913 m
Additional Information2 specifications
- Recommended Tractor Horsepower
- Minimum required for 9.1 m (30 ft) models: 201 kW 270 hp; Minimum required for 12.2 m (40 ft) models: 268 kW 360 hp
- Recommended Tractor Hydraulics
- Hydraulic oil pump required to operate ExactEmerge™ planter: 227 L/min 60 gpm; Tractor standby pressure: 15,500 kPa 155 bar (2300 psi); Hydraulic system working pressure: 20,684 kPa 207 bar (3000 psi); Hydraulic system burst pressure: 82,737 kPa 827 bar (12,000 psi)
