John Deere
ModelW260R Windrower
Mowing
The W260R is designed to meet your harvesting needs and productivity requirements.
Model / part number: 4091E
Key specifications
- Horsepower At 2,400 rpm (Imperial)
- 260.0 hp
- Fuel Capacity (Imperial)
- 150.0 U.S. gal.
- DEF Capacity (Imperial)
- 7.0 U.S. gal.
- Low Range (Imperial)
- 16.0 mph
Technical specifications
68 specifications
Key Specs14 details
- Horsepower At 2,400 rpm (Imperial)
- 260.0 hp
- Horsepower At 2,400 rpm (Metric)
- 193.9 kW
- Fuel Capacity (Imperial)
- 150.0 U.S. gal.
- Fuel Capacity (Metric)
- 568.0 L
- DEF Capacity (Imperial)
- 7.0 U.S. gal.
- DEF Capacity (Metric)
- 26.5 L
- Low Range (Imperial)
- 16.0 mph
- Low Range (Metric)
- 25.6 km/h
- High Range 2 Speed/Mid Range 3 Speed (Imperial)
- 24.0 mph
- High Range 2 Speed/Mid Range 3 Speed (Metric)
- 38.4 km/h
- Under Frame Clearance (Imperial)
- 44.0 in.
- Under Frame Clearance (Metric)
- 112.0 cm
- Total Weight (Imperial)
- 15640.0 lb.
- Total Weight (Metric)
- 7094.0 kg
Engine14 details
- Horsepower At 2,400 rpm (Imperial)
- 260.0 hp
- Horsepower At 2,400 rpm (Metric)
- 193.9 kW
- Horsepower Peak At 2,200 rpm (Imperial)
- 285.0 hp
- Horsepower Peak At 2,200 rpm (Metric)
- 215.5 kW
- Number Of Cylinders
- 6
- Engine Displacement (Imperial)
- 415.0 cu in.
- Engine Displacement (Metric)
- 6.8 L
- Low Idle Engine Speed
- 900.0 rpm
- High Idle (No Load) Engine Speed
- 2450.0 rpm
- Rated Engine Speed
- 2400.0 rpm
- Oil Crankcase Capacity (With Filter) (Imperial)
- 33.2 U.S. qt
- Oil Crankcase Capacity (With Filter) (Metric)
- 31.4 L
- Cooling System (Imperial)
- 13.0 U.S. gal.
- Cooling System (Metric)
- 49.2 L
Hydraulic Platform Drive6 details
- Number Of Pumps (Rotary/Auger)
- 1
- Number Of Motors (Rotary/Auger)
- 1
- Pump Displacement (Imperial)
- 7.02 cu in.
- Pump Displacement (Metric)
- 115.0 cc
- Motor Displacement (Per Revolution) (Imperial)
- 4.6 cu in.
- Motor Displacement (Per Revolution) (Metric)
- 75.4 cm³
Hydraulics2 details
- Reservoir Capacity (Imperial)
- 25.0 U.S. gal.
- Reservoir Capacity (Metric)
- 94.5 L
Fuel4 details
- Fuel Capacity (Imperial)
- 150.0 U.S. gal.
- Fuel Capacity (Metric)
- 568.0 L
- DEF Capacity (Imperial)
- 7.0 U.S. gal.
- DEF Capacity (Metric)
- 26.5 L
Electrical System1 detail
- Alternator
- 240.0 amp
Speeds4 details
- Low Range (Imperial)
- 16.0 mph
- Low Range (Metric)
- 25.6 km/h
- High Range 2 Speed/Mid Range 3 Speed (Imperial)
- 24.0 mph
- High Range 2 Speed/Mid Range 3 Speed (Metric)
- 38.4 km/h
Cab5 details
- Cab Glass (Imperial)
- 76.2 sq ft
- Cab Glass (Metric)
- 7.08 m²
- Air Conditioner Refrigerant
- R134a
- Air Conditioner Capacity (Imperial)
- 6000 lb.
- Air Conditioner Capacity (Metric)
- 2700 kg
Display And Input2 details
- Display Size (Imperial)
- 10.0 in.
- Display Size (Metric)
- 25.4 cm
Dimensions (With Platform Installed)10 details
- Overall Length Without Platform (Imperial)
- 225.5 in.
- Overall Length Without Platform (Metric)
- 590.0 cm
- Overall Height (Imperial)
- 148.0 in.
- Overall Height (Metric)
- 376.0 cm
- Under Frame Clearance (Imperial)
- 44.0 in.
- Wheelbase (Imperial)
- 146.0 in.
- Under Frame Clearance (Metric)
- 112.0 cm
- Wheelbase (Metric)
- 371.0 cm
- Track Width (Imperial)
- 142.0 in.
- Track Width (Metric)
- 360.5 cm
Weight6 details
- Front Axle Weight (Imperial)
- 9880.0 lb.
- Front Axle Weight (Metric)
- 4481.0 kg
- Rear Axle Weight
- 5760.0 lb.
- Real Axle Weight
- 2613.0 kg
- Total Weight (Imperial)
- 15640.0 lb.
- Total Weight (Metric)
- 7094.0 kg
