John Deere
D636 Draper
Mowing
The D636 Draper Platform gives maximum windrower productivity for all crops, from grains to oilseed, and silage.
Current product detail page listed in the official John Deere AFME sitemap; this does not assert a 2026 model year or confirmed Eswatini stock.
The AFME sitemap includes model-year-specific and legacy listings. Confirm current model, configuration, and Eswatini availability with SwaziTrac before quoting.
Model / part number: 44C0E
Technical specification source: Official manufacturer technical data
Catalogue source: John Deere Africa & Middle East (AFME) · Checked 2026-10-04
Specifications
Key Specs10 specifications
- Cutterbar Type
- John Deere double-cut knives: 10.2 cm, 4 in.
- Cut Width (Length) (Imperial)
- 30.0 ft
- Cut Width (Length) (Metric)
- 9.1 m
- Reel Type
- Hydraulic
- Fingers
- Plastic
- Belt Width
- V-guided draper belt
- Belt Width (Imperial)
- 42.0 in.
- Belt Width (Metric)
- 106.7 cm
- Transport Length Hitch Extended (Imperial)
- 40.8 ft
- Transport Length Hitch Extended (Metric)
- 12.5 m
Cutterbar8 specifications
- Cutterbar Type
- John Deere double-cut knives: 10.2 cm, 4 in.
- Cut Width (Length) (Imperial)
- 30.0 ft
- Cut Width (Length) (Metric)
- 9.1 m
- Knife Drive
- Two hydraulic motors and two knife drives; Optional: Two hydraulic motors and two knife drives
- Knife Speed
- 520.0 rpm
- Stroke Length (Imperial)
- 3.9 in.
- Stroke Length (Metric)
- 98.0 mm
- Cutterbar Tilt
- Hydraulic, adjustable from cab
Reel9 specifications
- Reel Type
- Hydraulic
- Number Of Bats
- 6
- Fingers
- Plastic
- Diameter (Imperial)
- 44.0 in.
- Diameter (Metric)
- 111.8 cm
- Height Control
- Hydraulic, adjustable from cab
- Speed Control
- Multi-function lever, in cab
- Reel Lift
- Hydraulic, adjustable from cab
- Reel Fore And Aft
- Hydraulic, adjustable from cab
Draper And Decks7 specifications
- Belt Width
- V-guided draper belt
- Belt Width (Imperial)
- 42.0 in.
- Belt Width (Metric)
- 106.7 cm
- Delivery Opening Width Single Swath Opening (Imperial)
- 80.0 in.
- Delivery Opening Width Single Swath Opening (Metric)
- 203.2 cm
- Delivery Opening Width Double Swath Opening (Imperial)
- 54.0 in.
- Delivery Opening Width Double Swath Opening (Metric)
- 137.2 cm
Auxiliary Top Auger1 specifications
- Auxiliary Top Auger Type
- Optional: Factory-installed cross-auger
Dimensions8 specifications
- Operating Width (Imperial)
- 30.0 ft
- Operating Width (Metric)
- 9.1 m
- Transport Width Reel Fully Retracted (Imperial)
- 8.5 ft
- Transport Width Reel Fully Retracted (Metric)
- 2.6 m
- Transport Height (Imperial)
- 29.6 ft
- Transport Height (Metric)
- 2.44 m
- Transport Length Hitch Extended (Imperial)
- 40.8 ft
- Transport Length Hitch Extended (Metric)
- 12.5 m
Weight4 specifications
- Approximate Weight Base Platform Without Reel (Imperial)
- 3513.0 lb.
- Approximate Weight Base Platform Without Reel (Metric)
- 1232.0 kg
- Approximate Weight Base Platform With Reel (Imperial)
- 5975 lb.
- Approximate Weight Base Platform With Reel (Metric)
- 2710 kg
Gauge Wheels And Transportation2 specifications
- Gauge Wheels
- Optional: Adjustable castoring gauge wheel
- Integrated Slow Speed Transport System
- Self-contained transport, including hitch, jack and axle, is conveniently stored on the swather table
