John Deere
659 Hay Pickup
Hay and Forage Attachments
Discover enhanced harvesting efficiency with the 659 Hay Pickup. Equipped for challenging conditions, it offers durable performance, smooth crop flow, and reduced downtime.
Current product detail page listed in the official John Deere AFME sitemap; this does not assert a 2026 model year or confirmed Eswatini stock.
The AFME sitemap includes model-year-specific and legacy listings. Confirm current model, configuration, and Eswatini availability with SwaziTrac before quoting.
Model / part number: 019BKM
Technical specification source: Official manufacturer technical data
Catalogue source: John Deere Africa & Middle East (AFME) · Checked 2026-10-04
Specifications
Key Specs10 specifications
- Height (Imperial)
- 4.6 ft
- Height (Metric)
- 1.4 m
- Length (Imperial)
- 4.4 ft
- Length (Metric)
- 1.35 m
- Number Of Tines
- Four rows of 64 tines
- Auger
- Feed auger: Adjustable paddles
- Auger Diameter (Imperial)
- 22.0 in.
- Auger Diameter (Metric)
- 56.0 cm
- Weight (Imperial)
- 3131.0 lb.
- Weight (Metric)
- 1420.0 kg
Windrow Pickup24 specifications
- Pickup Width Transport Width (Imperial)
- 14.76 ft
- Pickup Width Transport Width (Metric)
- 4.5 m
- Pickup Width Operating Width (Tine To Tine) (Imperial)
- 13.6 ft
- Pickup Width Operating Width (Tine To Tine) (Metric)
- 4.15 m
- Overall Pickup Width Unfolded Gauge Wheels (Imperial)
- 18.5 ft
- Overall Pickup Width Unfolded Gauge Wheels (Metric)
- 5.65 m
- Effective Pickup Width (Imperial)
- 14.76 ft
- Effective Pickup Width (Metric)
- 4.5 m
- Height (Imperial)
- 4.6 ft
- Height (Metric)
- 1.4 m
- Length (Imperial)
- 4.4 ft
- Length (Metric)
- 1.35 m
- Number Of Tines
- Four rows of 64 tines
- Tine Spacing (Imperial)
- 2.56 in.
- Tine Spacing (Metric)
- 65.0 mm
- Stripper Diameter (Imperial)
- 9.0 in.
- Stripper Diameter (Metric)
- 230.0 mm
- Gauge Wheels (Two)
- Two manual folding pneumatic gauge wheels - 18.5 x 8.5-8PR
- Gauge Shoes
- Two skid shoes
- Auger
- Feed auger: Adjustable paddles
- Auger Diameter (Imperial)
- 22.0 in.
- Auger Diameter (Metric)
- 56.0 cm
- Weight (Imperial)
- 3131.0 lb.
- Weight (Metric)
- 1420.0 kg
Additional Information1 specifications
- Date Collected
- 2020-02-18
