John Deere
649 Hay Pickup
Hay and Forage Attachments
Enhance forage efficiency with the 649 Hay Pickup. Designed for high yields and challenging conditions, it offers premium features for optimal performance and reliability.
Current product detail page listed in the official John Deere AFME sitemap; this does not assert a 2026 model year or confirmed Eswatini stock.
The AFME sitemap includes model-year-specific and legacy listings. Confirm current model, configuration, and Eswatini availability with SwaziTrac before quoting.
Model / part number: 018BKM
Technical specification source: Official manufacturer technical data
Catalogue source: John Deere Africa & Middle East (AFME) · Checked 2026-10-04
Specifications
Key Specs10 specifications
- Height (Imperial)
- 4.6 ft
- Height (Metric)
- 1.4 m
- Length (Imperial)
- 4.4 ft
- Length (Metric)
- 1.35 m
- Number Of Tines
- Four rows of 56 tines
- Auger
- Feed auger: Adjustable paddles
- Auger Diameter (Imperial)
- 22.0 in.
- Auger Diameter (Metric)
- 56.0 cm
- Weight (Imperial)
- 2932.0 lb.
- Weight (Metric)
- 1330.0 kg
Windrow Pickup24 specifications
- Pickup Width Transport Width (Imperial)
- 13.1 ft
- Pickup Width Transport Width (Metric)
- 4.0 m
- Pickup Width Operating Width (Tine To Tine) (Imperial)
- 11.9 ft
- Pickup Width Operating Width (Tine To Tine) (Metric)
- 3.64 m
- Overall Pickup Width Unfolded Gauge Wheels (Imperial)
- 16.7 ft
- Overall Pickup Width Unfolded Gauge Wheels (Metric)
- 5.1 m
- Effective Pickup Width (Imperial)
- 13.1 ft
- Effective Pickup Width (Metric)
- 4.0 m
- Height (Imperial)
- 4.6 ft
- Height (Metric)
- 1.4 m
- Length (Imperial)
- 4.4 ft
- Length (Metric)
- 1.35 m
- Number Of Tines
- Four rows of 56 tines
- Tine Spacing (Imperial)
- 2.56 in.
- Tine Spacing (Metric)
- 65.0 mm
- Stripper Diameter (Imperial)
- 9.0 in.
- Stripper Diameter (Metric)
- 230.0 mm
- Gauge Wheels (Two)
- Two manual folding pneumatic gauge wheels - 18.5 x 8.5-8PR
- Gauge Shoes
- Two skid shoes
- Auger
- Feed auger: Adjustable paddles
- Auger Diameter (Imperial)
- 22.0 in.
- Auger Diameter (Metric)
- 56.0 cm
- Weight (Imperial)
- 2932.0 lb.
- Weight (Metric)
- 1330.0 kg
Additional Information1 specifications
- Date Collected
- 2020-02-18
